A 60 +/-5 mils thick fiberglass reinforced, polymer modified bitumen based sheet membrane used in conjunction with the Roybond Primer-Adhesive Series. The typical uses are as a waterproofing membrane on bridge or parking garage decks, highways and tunnels.
Overview
The Royston 10A Easy Pave is a state-of-the-art waterproofing membrane designed for superior performance in demanding environments. Comprised of a prefabricated reinforced laminate, this membrane features an impregnated woven fiberglass and a high-strength inner core, all sandwiched between layers of polymer-modified bitumen. The advanced design allows for flexible installation, accommodating minor movement due to thermal expansion and contraction, while offering excellent tensile strength and puncture resistance.
Read more
The spun-bonded polyester top surface enhances protection against mechanical damage from construction traffic, promoting durability and longevity. A unique 3-inch leading edge ensures a positive compound-to-compound seal at the overlap. For additional sealing, transverse seals can be easily executed using Royston Flex-Flo Adhesive Sealant, Royston 104 Caulkable Mastic, or heat sealing methods. These characteristics make it an ideal solution for a variety of applications where reliability and performance are critical.
Key Features
- Thickness: 60 +/- 5 mils, ensuring uniformity and reliability.
- Reinforcement: Woven fiberglass provides exceptional tensile strength.
- Flexible Membrane: Allows for minor movement due to thermal fluctuations.
- Cold Applied Installation: Eliminates risks associated with hot liquids.
- Leading Edge Technology: 3-inch leading edge for a watertight seam.
Applications
- Bridges
- Highways
- Tunnels
- Airport runways
- Balconies
- Parking garages
Benefits
- Superior protection against moisture permeation.
- Enhanced service life expectancy.
- Fast installation to reduce project timelines.
- Lower traffic control costs due to efficient setup.
- Compatible with a range of Roybond Primer-Adhesive products.
The Royston 10A Easy Pave provides a robust solution for waterproofing needs, enhancing structural integrity and extending the lifespan of surfaces exposed to challenging conditions. Its advanced features and flexible application make it a trusted choice in the construction industry.
A 60 +/-5 mils thick fiberglass reinforced, polymer modified bitumen based sheet membrane used in conjunction with the Roybond Primer-Adhesive Series. The typical uses are as a waterproofing membrane on bridge or parking garage decks, highways and tunnels.
Overview
The Royston 10A Easy Pave is a state-of-the-art waterproofing membrane designed for superior performance in demanding environments. Comprised of a prefabricated reinforced laminate, this membrane features an impregnated woven fiberglass and a high-strength inner core, all sandwiched between layers of polymer-modified bitumen. The advanced design allows for flexible installation, accommodating minor movement due to thermal expansion and contraction, while offering excellent tensile strength and puncture resistance.
Read more
The spun-bonded polyester top surface enhances protection against mechanical damage from construction traffic, promoting durability and longevity. A unique 3-inch leading edge ensures a positive compound-to-compound seal at the overlap. For additional sealing, transverse seals can be easily executed using Royston Flex-Flo Adhesive Sealant, Royston 104 Caulkable Mastic, or heat sealing methods. These characteristics make it an ideal solution for a variety of applications where reliability and performance are critical.
Key Features
- Thickness: 60 +/- 5 mils, ensuring uniformity and reliability.
- Reinforcement: Woven fiberglass provides exceptional tensile strength.
- Flexible Membrane: Allows for minor movement due to thermal fluctuations.
- Cold Applied Installation: Eliminates risks associated with hot liquids.
- Leading Edge Technology: 3-inch leading edge for a watertight seam.
Applications
- Bridges
- Highways
- Tunnels
- Airport runways
- Balconies
- Parking garages
Benefits
- Superior protection against moisture permeation.
- Enhanced service life expectancy.
- Fast installation to reduce project timelines.
- Lower traffic control costs due to efficient setup.
- Compatible with a range of Roybond Primer-Adhesive products.
The Royston 10A Easy Pave provides a robust solution for waterproofing needs, enhancing structural integrity and extending the lifespan of surfaces exposed to challenging conditions. Its advanced features and flexible application make it a trusted choice in the construction industry.
Specifications
| Material | Spun bonded polyester |
|---|---|
| Color | Black |
| Thickness | 60±5 mils |
