A 70 +/-5 mils thick fiberglass reinforced, polymer modified bitumen based sheet membrane used in conjunction with the Roybond Primer-Adhesive Series. The typical uses are as a waterproofing membrane on bridge or parking garage decks, highways and tunnels.
Overview
Royston 10A- 65 is a high-performance waterproofing membrane designed for a variety of demanding applications. Its unique composition features a prefabricated reinforced laminate, constructed with an impregnated woven fiberglass and a high strength inner core, strategically sandwiched between two layers of polymer modified bitumen. This construction not only provides exceptional durability but also ensures easy installation.
Designed for maximum resilience, the membrane’s spun bonded polyester top surface affords protection against mechanical damage typically associated with construction traffic. Royston 10A- 65 is compatible with the Roybond Primer-Adhesive Series, facilitating efficient adhesion and application.
Read more
With a thickness of 70 +/- 5 mils, the membrane is optimal for waterproofing applications, particularly in bridge and parking garage decks, highways, and tunnels. The product ensures a watertight seal thanks to its innovative 3-inch leading edge design, which allows for a positive compound-to-compound seal at the overlaps.
Key Features
- High strength inner core for added durability
- Spun bonded polyester surface for protection against mechanical damage
- Flexible membrane accommodates thermal expansion and contraction
- Easy transverse seals with Royston Flex-Flo Adhesive Sealant or heat sealing
- 70 +/- 5 mils thickness for reliable waterproofing
Applications
- Bridges
- Highways
- Tunnels
- Airport runways
- Balconies
- Parking garages
Benefits
- Superior tensile strength and puncture resistance
- Enhanced service life expectancy
- Protection against structural damage from moisture
- Fast installation reduces traffic control costs
- Environment-friendly cold applied installation minimizes risks
The Royston 10A- 65 membrane stands out as a reliable solution for waterproofing in various construction projects, providing durability and performance under challenging conditions. Its innovative design and material ensure a long-lasting, effective barrier against water infiltration, making it an essential choice for industry professionals.
A 70 +/-5 mils thick fiberglass reinforced, polymer modified bitumen based sheet membrane used in conjunction with the Roybond Primer-Adhesive Series. The typical uses are as a waterproofing membrane on bridge or parking garage decks, highways and tunnels.
Overview
Royston 10A- 65 is a high-performance waterproofing membrane designed for a variety of demanding applications. Its unique composition features a prefabricated reinforced laminate, constructed with an impregnated woven fiberglass and a high strength inner core, strategically sandwiched between two layers of polymer modified bitumen. This construction not only provides exceptional durability but also ensures easy installation.
Designed for maximum resilience, the membrane’s spun bonded polyester top surface affords protection against mechanical damage typically associated with construction traffic. Royston 10A- 65 is compatible with the Roybond Primer-Adhesive Series, facilitating efficient adhesion and application.
Read more
With a thickness of 70 +/- 5 mils, the membrane is optimal for waterproofing applications, particularly in bridge and parking garage decks, highways, and tunnels. The product ensures a watertight seal thanks to its innovative 3-inch leading edge design, which allows for a positive compound-to-compound seal at the overlaps.
Key Features
- High strength inner core for added durability
- Spun bonded polyester surface for protection against mechanical damage
- Flexible membrane accommodates thermal expansion and contraction
- Easy transverse seals with Royston Flex-Flo Adhesive Sealant or heat sealing
- 70 +/- 5 mils thickness for reliable waterproofing
Applications
- Bridges
- Highways
- Tunnels
- Airport runways
- Balconies
- Parking garages
Benefits
- Superior tensile strength and puncture resistance
- Enhanced service life expectancy
- Protection against structural damage from moisture
- Fast installation reduces traffic control costs
- Environment-friendly cold applied installation minimizes risks
The Royston 10A- 65 membrane stands out as a reliable solution for waterproofing in various construction projects, providing durability and performance under challenging conditions. Its innovative design and material ensure a long-lasting, effective barrier against water infiltration, making it an essential choice for industry professionals.
Specifications
| Thickness | 70±5 mils |
|---|---|
| Material | ¼ mil mylar film |
| Color | Black |
Downloads
Royston 10A-65
pdfDownload
